Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.2 m
Specs
Main
| Maker | Dragonfly |
| Maker website | https://www.dragonfly.dk |
| Model | Dragonfly 920 - Touring |
| First built hull | 1996 |
| Version | Touring |
| Boat type | Sail |
| Category | Trimaran Boats |
| Hull type | Trimaran |
| Hull material | Fiberglass |
General
| Mast height | 14.36 m |
| Length overall | 9.2 m |
| Length at waterline | 8.78 m |
| Beam overall | 6.83 m |
| Beam hull | 1.55 m |
| Draft maximum | 1.55 m |
| Displacement | 2,599.99 kg |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder (main hull) |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Børge Quorning ; Jens Quorning |
| Website | http://www.trimarans.com/ |
Rig & Sails
| Rotating spars | |
| Mast | 47.11 |
| Spars | Mast and boom in Aluminum |
| Spreaders angle | Swept-back (diamond) |
| Upwind sail area | 59.46 sq.m |
| Downwind sail area | 102.01 sq.m |
Engine
| Engine A | |
| Power | 15 HP |
| Type | outboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 31.98 |
| Downwind SA to Displacement | 54.87 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.19 |
| Capsize Screening Formula (CSF) | 5.01 |
