Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
5.49 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Seascape Edition |
| Maker website | https://www.seascape-edition.com |
| Model | Seascape 18 Standard |
| First built hull | 2008 |
| Version | Standard |
| Price | 20,900 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Length overall | 5.49 m |
| Beam overall | 2.16 m |
| Draft maximum | 1.25 m |
| Displacement | 499.86 kg |
| Ballast weight | 125.19 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 2 transom hung rudders |
| Cockpit | Open aft cockpit |
| Unsinkable | |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Samuel Manuard |
| Website | http://sam.manuard.free.fr/ |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Carbon fiber |
| Standing rigging | 1x19 strand wire |
| Upwind sail area | 23.69 sq.m |
| Downwind sail area | 46.54 sq.m |
| Mainsail A | 156.00 |
| Spinnaker A | 344.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Outboard Engine |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.09 |
| Upwind SA to Displacement | 38.25 |
| Downwind SA to Displacement | 75.15 |
| Hull Displacement Speed | 0.09 |
| Ballast to Displacement (B/D) | 0.25 |
| Capsize Screening Formula (CSF) | 2.75 |
