Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.32 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Seascape Edition |
| Maker website | https://www.seascape-edition.com |
| Model | Seascape 24 |
| First built hull | 2016 |
| Price | 45,000 € |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Length overall | 7.32 m |
| Beam overall | 2.5 m |
| Headroom | 1.37 m |
| Draft maximum | 2.04 m |
| Displacement | 889.95 kg |
| Ballast weight | 319.78 kg |
| Ballast type | Glass fiber/vinylester (infusion) fin with lead bulb |
| Helm | 1 tiller |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
| Unsinkable | |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Samuel Manuard |
| Website | http://sam.manuard.free.fr/ |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Carbon fiber |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 41.99 sq.m |
| Downwind sail area | 91.97 sq.m |
| Mainsail A | 269.00 |
| Spinnaker A | 721.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Outboard Engine |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.12 |
| Upwind SA to Displacement | 46.16 |
| Downwind SA to Displacement | 101.09 |
| Hull Displacement Speed | 0.12 |
| Ballast to Displacement (B/D) | 0.36 |
| Capsize Screening Formula (CSF) | 2.62 |
