Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.99 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Seascape Edition |
| Maker website | https://www.seascape-edition.com |
| Model | Seascape 27 |
| First built hull | 2012 |
| Price | 63,000 € |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Length overall | 7.99 m |
| Length at waterline | 7.99 m |
| Beam overall | 2.56 m |
| Draft maximum | 1.98 m |
| Displacement | 1,379.83 kg |
| Ballast weight | 610.08 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 1 tiller |
| Rudder | 2 transom hung rudders |
| Cockpit | Open aft cockpit |
| Unsinkable | |
| Trailerable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Samuel Manuard |
| Website | http://sam.manuard.free.fr/ |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Carbon fiber |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 48.03 sq.m |
| Downwind sail area | 108.05 sq.m |
| Mainsail A | 301.00 |
| Spinnaker A | 861.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 10 HP |
| Type | Outboard or inboard engine ; Diesel for inboard engine, Gas for outboard |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.11 |
| Upwind SA to Displacement | 39.41 |
| Downwind SA to Displacement | 88.66 |
| Hull Displacement Speed | 0.11 |
| Displacement to Length (D/L) | 6.86 |
| Ballast to Displacement (B/D) | 0.44 |
| Capsize Screening Formula (CSF) | 2.32 |
