Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
7.99 m
Specs
Main
| Maker | Smap Neptune |
| Model | Trident 80 Deep draft |
| First built hull | 1975 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 10.44 kmh |
| Length overall | 7.99 m |
| Length at waterline | 7.16 m |
| Beam overall | 2.93 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.58 m |
| Displacement | 2,350.06 kg |
| Ballast weight | 949.82 kg |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Daniel Tortarolo |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 36.98 sq.m |
| Downwind sail area | 65.03 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 10 HP |
| Type | outboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 21.27 |
| Downwind SA to Displacement | 37.42 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 6.5 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 2.22 |
