1975 Smap Neptune Trident 80 Shoal draft

1670

Report error

1975 Smap Neptune Trident 80 Shoal draft

No gallery images

1975 Smap Neptune Trident 80 Shoal draft
Preview

Boat Overview

Specs

Main
NameValue
MakerSmap Neptune
ModelTrident 80 Shoal draft
First built hull1975
VersionShoal draft
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
NameValue
Top speed10.44 kmh
Length overall7.99 m
Length at waterline7.16 m
Beam overall2.93 m
Headroom1.56 m
Draft maximum1.25 m
Displacement2,350.06 kg
Ballast weight949.82 kg
Helm1 tiller
Rudder1 semi-spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioDaniel Tortarolo
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area36.98 sq.m
Downwind sail area65.03 sq.m
Mainsail A118.00
Spinnaker A581.00
Engine
NameValue
Engine A
Power10 HP
TypeOutboard or inboard engine ; Diesel for inboard engine, Gas for outboard
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement21.27
Downwind SA to Displacement37.42
Hull Displacement Speed 0.05
Displacement to Length (D/L) 6.5
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 2.22
