Boat Overview

Boat Description

Discover the Southerly 420: A Masterclass in Sailing Versatility

The Southerly 420 stands as a shining beacon in yacht craftsmanship, boasting a blend of unparalleled performance with the luxury of a variable draft swing keel. This remarkable feature allows sailors to transition from deep waters to shallow bays with ease, making the Southerly 420 a vessel for all seas.

Performance Sailing with a Solent Rig

The Southerly 420 employs a sophisticated Solent rig, complemented by twin headstays. This configuration ensures supreme handling and sail control, enabling both novices and veteran sailors to harness the wind to its full potential. The inclusion of a self-tacking jib and furling headsails promotes a smooth, nearly effortless sailing experience.
Innovation in Sail Handling

In-mast furling mainsail technology lies at the heart of convenience on the Southerly 420, streamlining the sail management process and allowing for a more relaxed and enjoyable journey on the water.

Elevated Comfort in the Raised Saloon

The raised saloon of the Southerly 420 is not just a retreat; it's a panoramic observation lounge. Every nautical journey is accompanied by visual splendor, ensuring that no horizons are left unadmired.

Advanced Hull Design

A striking feature is the central skeg, crafted purposefully to protect the propeller from unseen underwater hazards. This, combined with semi-balanced twin rudders, empowers the Southerly 420 with incredible maneuverability and stability, even in the most challenging conditions.

  • southerly-420-2020_Plan View.png
    • Plan view
    0.09MB Download

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerSoutherly
Maker websitehttps://www.southerly-yachts.com
Model420
First built hull2020
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialMonohull
Cabins2
Births4
Heads2
General
NameValue
Top speed13.02 kmh
Mast height18.78 m
Length overall13.01 m
Length at waterline11.13 m
Beam overall4.05 m
Draft maximum2.47 m
Displacement11,341.16 kg
Ballast weight3,670.01 kg
Helm2 wheels
Rudder2 spade rudders
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioHumphreys Yacht Design
Websitehttp://www.humphreysdesign.com
Rig & Sails
NameValue
Mast61.6
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area73.58 sq.m
Mainsail A468
Headsail A334
Engine
NameValue
Engine A
MakerYanmar
Power57 HP
TypeInboard engine ; Diesel
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Upwind SA to Displacement14.83
Displacement to Length (D/L) 8.11
Ballast to Displacement (B/D) 0.32
Capsize Screening Formula (CSF) 1.81
