Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.45 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Pogo Structure |
| Maker website | https://www.pogostructures.com |
| Model | Pogo 30 Swing keel |
| First built hull | 2013 |
| Version | Swing keel |
| Price | 92,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Top speed | 11.78 kmh |
| Length overall | 9.45 m |
| Length at waterline | 8.87 m |
| Beam overall | 3.69 m |
| Draft maximum | 2.5 m |
| Displacement | 2,800.02 kg |
| Ballast weight | 944.83 kg |
| Ballast type | Glass fiber/vinylester (infusion) fin with lead bulb |
| Helm | 2 tillers |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Finot Conq Architectes |
| Website | http://www.finot-conq.com |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 27 ° |
| Upwind sail area | 60.02 sq.m |
| Downwind sail area | 125.98 sq.m |
| Mainsail A | 366.00 |
| Spinnaker A | 990.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 18 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.08 |
| Upwind SA to Displacement | 30.72 |
| Downwind SA to Displacement | 64.49 |
| Hull Displacement Speed | 0.08 |
| Displacement to Length (D/L) | 7.23 |
| Ballast to Displacement (B/D) | 0.34 |
| Capsize Screening Formula (CSF) | 2.64 |
