Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.19 m
Specs
Main
Name | Value |
---|---|
Maker | Pogo Structure |
Maker website | https://www.pogostructures.com |
Model | Pogo 40S2 |
First built hull | 2009 |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Mast height | 19.02 m |
Length overall | 12.19 m |
Beam overall | 4.3 m |
Draft maximum | 2.77 m |
Displacement | 4,500.09 kg |
Ballast type | Glass fiber/vinylester (infusion) fin with lead bulb |
Helm | 2 tillers |
Rudder | 2 spade rudders |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Finot Conq Architectes |
Website | http://www.finot-conq.com |
Rig & Sails
Name | Value |
---|---|
Mast | 62.4 |
Spars | Mast in Carbon fiber and boom in Aluminum |
Standing rigging | Single-strand (ROD) |
Spreaders angle | Swept-back |
Upwind sail area | 115.01 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 30 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 42.92 |
Capsize Screening Formula (CSF) | 2.63 |
