Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
6.89 m
Specs
Main
Name | Value |
---|---|
Maker | Sunbeam Yachts |
Maker website | https://www.sunbeam-yachts.com |
Model | Sunbeam 22.1 |
First built hull | 2016 |
Price | 30,000 € |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 10.04 kmh |
Mast height | 10.42 m |
Length overall | 6.89 m |
Length at waterline | 6.64 m |
Beam overall | 2.5 m |
Draft maximum | 1.43 m |
Displacement | 1,299.99 kg |
Ballast weight | 229.97 kg |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | J&J Yacht Design |
Website | https://jnj.design |
Rig & Sails
Name | Value |
---|---|
Mast | 34.2 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 27.96 sq.m |
Downwind sail area | 52.03 sq.m |
Mainsail A | 183.00 |
Spinnaker A | 377.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 23.88 |
Downwind SA to Displacement | 44.42 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 6.26 |
Ballast to Displacement (B/D) | 0.18 |
Capsize Screening Formula (CSF) | 2.31 |
