Specs

Main
MakerWauquiez
Maker websitehttps://www.wauquiez.com
ModelOptio Swing keel
First built hull2014
VersionSwing keel
Price94,500 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed11.44 kmh
Mast height13.23 m
Length overall9.02 m
Length at waterline8.56 m
Beam overall2.56 m
Draft maximum2.19 m
Displacement2,000 kg
Ballast weight900 kg
Ballast typeCast iron
Helm1 tiller
Rudder2 spade rudders
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioBerret-Racoupeau Yacht Design
Websitehttp://www.berret-racoupeau.com/
Rig & Sails
Mast43.4
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD) discontinuous
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area43.48 sq.m
Downwind sail area96.53 sq.m
Engine
Engine B
Power14 HP
TypeInboard
Storage
Fuel tank A40.13 liter
Water tank A49.97 liter
Holding tank A34.83 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 27.85
Upwind SA to Displacement27.85
Downwind SA to Displacement61.83
Hull Displacement Speed 7.1
Displacement to Length (D/L) 88.71
Ballast to Displacement (B/D) 0.45
Capsize Screening Formula (CSF) 2.05
