Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
13.01 m
Specs
Main
| Maker | Wauquiez |
| Maker website | https://www.wauquiez.com |
| Model | Pilot Saloon 42 Standard |
| First built hull | 2018 |
| Version | Standard |
| Price | 380,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 13.97 kmh |
| Length overall | 13.01 m |
| Length at waterline | 12.8 m |
| Beam overall | 4.33 m |
| Beam hull | 2.16 m |
| Draft maximum | 1.68 m |
| Displacement | 11,999.78 kg |
| Ballast weight | 4,349.95 kg |
| Ballast type | Cast iron |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Olivier Racoupeau |
| Website | http://www.berret-racoupeau.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 89.47 sq.m |
| Downwind sail area | 171.03 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 80 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 17.36 |
| Downwind SA to Displacement | 33.19 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 8.68 |
| Ballast to Displacement (B/D) | 0.36 |
| Capsize Screening Formula (CSF) | 1.91 |
