Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
14.81 m
Specs
Main
Name | Value |
---|---|
Maker | Wauquiez |
Maker website | https://www.wauquiez.com |
Model | Pilot Saloon 48 Shoal draft |
First built hull | 2016 |
Version | Shoal draft |
Price | 450,000 € |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 13.95 kmh |
Length overall | 14.81 m |
Length at waterline | 12.53 m |
Beam overall | 4.6 m |
Headroom | 2.04 m |
Draft maximum | 1.56 m |
Displacement | 14,379.77 kg |
Ballast weight | 4,080.06 kg |
Ballast type | Lead |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Berret-Racoupeau Yacht Design |
Website | http://www.berret-racoupeau.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire discontinuous |
Number of spreaders | 3 |
Spreaders angle | Swept-back |
Upwind sail area | 102.01 sq.m |
Downwind sail area | 212 sq.m |
Mainsail A | 560.00 |
Spinnaker A | 1722.00 |
Spinnaker A | 915.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 17.55 |
Downwind SA to Displacement | 36.47 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 8.59 |
Ballast to Displacement (B/D) | 0.28 |
Capsize Screening Formula (CSF) | 1.91 |
