Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
9.48 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Westerly |
| Model | Fulmar 32 - Keel and centerboard |
| First built hull | 1980 |
| Version | Keel and centerboard |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 10.99 kmh |
| Mast height | 12.98 m |
| Length overall | 9.48 m |
| Length at waterline | 7.92 m |
| Beam overall | 3.08 m |
| Draft maximum | 1.77 m |
| Displacement | 4,549.98 kg |
| Ballast weight | 1,969.95 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Edward Dubois |
Rig & Sails
| Name | Value |
|---|---|
| Mast | 42.6 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 52.58 sq.m |
| Downwind sail area | 94.11 sq.m |
| Mainsail A | 253.00 |
| Spinnaker A | 760.00 |
| Spinnaker A | 194.00 |
| Spinnaker A | 93.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 19.48 |
| Downwind SA to Displacement | 34.86 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.83 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 1.88 |
