Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
7.92 m
Specs
Main
| Maker | Westerly |
| Model | Griffon 26 Fin keel |
| First built hull | 1979 |
| Version | Fin keel |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 10.03 kmh |
| Length overall | 7.92 m |
| Length at waterline | 6.61 m |
| Beam overall | 2.87 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.25 m |
| Displacement | 2,676.19 kg |
| Ballast weight | 1,235.13 kg |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Edward Dubois |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 38.28 sq.m |
| Downwind sail area | 73.67 sq.m |
Engine
| Engine A | |
| Power | 20 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 20.2 |
| Downwind SA to Displacement | 38.87 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 6.24 |
| Ballast to Displacement (B/D) | 0.46 |
| Capsize Screening Formula (CSF) | 2.08 |
