1979 Westerly Griffon 26 Twin keel

1671

Report error

1979 Westerly Griffon 26 Twin keel

No gallery images

Boat Overview

Type
Sail
Maker
Westerly
Hull type
Monohull
Hull Material
Composite_Material
Category
Cruiser Boats
Boat length (LOA)
7.92 m
See all details

Overview

Performance & Ratios

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Hide empty fields

Main

Name	Value
Maker	Westerly
Model	Griffon 26 Twin keel
First built hull	1979
Version	Twin keel
Boat type	Sail
Category	Cruiser Boats
Hull type	Monohull
Hull material	Monohull

General

Name	Value
Top speed	10.03 kmh
Length overall	7.92 m
Length at waterline	6.61 m
Beam overall	2.87 m
Headroom	1.56 m
Draft maximum	0.98 m
Displacement	2,676.19 kg
Ballast weight	1,235.13 kg
Helm	1 tiller
Rudder	1 transom hung rudder
Cockpit	Closed aft cockpit

Designer

Name	Value
Naval architect
Name/Studio	Edward Dubois

Rig & Sails

Name	Value
Spars	Mast and boom in Aluminum
Standing rigging	1x19 strand wire continuous
Number of spreaders	1
Spreaders angle	0 °
Upwind sail area	38.28 sq.m
Downwind sail area	73.67 sq.m
Mainsail A	147.00
Spinnaker A	646.00
Spinnaker A	134.00

Engine

Name	Value
Engine A
Power	20 HP
Type	Inboard engine ; Diesel
Engine B

Storage

Name	Value
No data

Performance & Ratios

Hide empty fields

Detail

Name	Value
Sail Area to Displacement (SA/D)	0.05
Upwind SA to Displacement	20.2
Downwind SA to Displacement	38.87
Hull Displacement Speed	0.05
Displacement to Length (D/L)	6.24
Ballast to Displacement (B/D)	0.46
Capsize Screening Formula (CSF)	2.08
