Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
8.57 m
Specs
Main
| Maker | Westerly |
| Model | Konsort Duo 29 |
| First built hull | 1985 |
| Boat type | Sail |
| Category | Other Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 10.91 kmh |
| Mast height | 10.91 m |
| Length overall | 8.57 m |
| Length at waterline | 7.83 m |
| Beam overall | 3.08 m |
| Draft maximum | 1.04 m |
| Displacement | 4,579.92 kg |
| Ballast weight | 1,450.13 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | John Laurent Giles |
| Website | http://www.laurentgilesarchive.com/ |
Rig & Sails
| Mast | 35.8 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 47.94 sq.m |
| Downwind sail area | 85.19 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 28 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 17.68 |
| Downwind SA to Displacement | 31.42 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.79 |
| Ballast to Displacement (B/D) | 0.32 |
| Capsize Screening Formula (CSF) | 1.87 |
