Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
11.77 m
Specs
Main
Name | Value |
---|---|
Maker | Westerly |
Model | Sealord 39 Sloop |
First built hull | 1983 |
Version | Sloop |
Boat type | Sail |
Category | Cruiser BoatsCenter Cockpit Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 12.3 kmh |
Mast height | 14.75 m |
Length overall | 11.77 m |
Length at waterline | 9.94 m |
Beam overall | 4.02 m |
Draft maximum | 1.71 m |
Displacement | 8,391.91 kg |
Ballast weight | 3,629.19 kg |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Central cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Edward Dubois |
Rig & Sails
Name | Value |
---|---|
Mast | 48.4 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 89.84 sq.m |
Downwind sail area | 169.83 sq.m |
Mainsail A | 352.00 |
Spinnaker A | 1476.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 22.13 |
Downwind SA to Displacement | 41.83 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 7.65 |
Ballast to Displacement (B/D) | 0.43 |
Capsize Screening Formula (CSF) | 2 |
