Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.43 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | IMX 38 |
| First built hull | 1992 |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.04 kmh |
| Length overall | 11.43 m |
| Length at waterline | 9.51 m |
| Beam overall | 3.69 m |
| Draft maximum | 2.13 m |
| Displacement | 5,350.12 kg |
| Ballast weight | 2,800.02 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 89.09 sq.m |
| Downwind sail area | 151.9 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 28 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 29.62 |
| Downwind SA to Displacement | 50.5 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.48 |
| Ballast to Displacement (B/D) | 0.52 |
| Capsize Screening Formula (CSF) | 2.13 |
