Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.13 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | IMX 40 |
| First built hull | 2000 |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.65 kmh |
| Length overall | 12.13 m |
| Length at waterline | 10.52 m |
| Beam overall | 3.84 m |
| Beam hull | 1.89 m |
| Draft maximum | 2.44 m |
| Displacement | 6,830.19 kg |
| Ballast weight | 2,399.96 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Standing rigging | Single-strand (ROD) |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 102.1 sq.m |
| Downwind sail area | 169.64 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 39 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 28.85 |
| Downwind SA to Displacement | 47.93 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.87 |
| Ballast to Displacement (B/D) | 0.35 |
| Capsize Screening Formula (CSF) | 2.04 |
