Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelIMX 45
First built hull2002
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed13.52 kmh
Length overall13.75 m
Length at waterline12.01 m
Beam overall4.18 m
Beam hull2.04 m
Draft maximum2.74 m
Displacement9,100 kg
Ballast weight4,130 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Carbon fiber
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area128.58 sq.m
Downwind sail area228.08 sq.m
Engine
Engine B
Power55 HP
TypeInboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 29.99
Upwind SA to Displacement29.99
Downwind SA to Displacement53.2
Hull Displacement Speed 8.41
Displacement to Length (D/L) 146.43
Ballast to Displacement (B/D) 0.45
Capsize Screening Formula (CSF) 2.02
