Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
9.27 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-312 Fractional rigging |
| First built hull | 1989 |
| Version | Fractional rigging |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 10.7 kmh |
| Length overall | 9.27 m |
| Length at waterline | 7.53 m |
| Beam overall | 2.77 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.74 m |
| Displacement | 3,355.22 kg |
| Ballast weight | 1,650.17 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 52.68 sq.m |
| Downwind sail area | 84.54 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 17 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 23.9 |
| Downwind SA to Displacement | 38.36 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 6.66 |
| Ballast to Displacement (B/D) | 0.49 |
| Capsize Screening Formula (CSF) | 1.87 |
