Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
9.27 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | X-312 Mast head rigging |
First built hull | 1989 |
Version | Mast head rigging |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 10.7 kmh |
Length overall | 9.27 m |
Length at waterline | 7.53 m |
Beam overall | 2.77 m |
Headroom | 1.56 m |
Draft maximum | 1.74 m |
Displacement | 3,355.22 kg |
Ballast weight | 1,650.17 kg |
Ballast type | Cast iron / lead fin |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Niels Jeppesen |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Number of spreaders | 2 |
Spreaders angle | 0 ° |
Upwind sail area | 50.73 sq.m |
Downwind sail area | 89.65 sq.m |
Mainsail A | 221.00 |
Spinnaker A | 744.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 17 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 23.02 |
Downwind SA to Displacement | 40.68 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 6.66 |
Ballast to Displacement (B/D) | 0.49 |
Capsize Screening Formula (CSF) | 1.87 |
