Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.09 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-332 Standard |
| First built hull | 1994 |
| Version | Standard |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 11.59 kmh |
| Length overall | 10.09 m |
| Length at waterline | 8.57 m |
| Beam overall | 3.08 m |
| Beam hull | 1.86 m |
| Draft maximum | 1.56 m |
| Displacement | 4,349.95 kg |
| Ballast weight | 1,749.96 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 68.19 sq.m |
| Downwind sail area | 109.35 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 18 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 26.03 |
| Downwind SA to Displacement | 41.73 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.1 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 1.9 |
