2007 X-Yachts X-34 Shoal draft

1539

Report error

2007 X-Yachts X-34 Shoal draft
2007 X-Yachts X-34 Shoal draft
2007 X-Yachts X-34 Shoal draft
2007 X-Yachts X-34 Shoal draft
2007 X-Yachts X-34 Shoal draft
Preview
2007 X-Yachts X-34 Shoal draft
Preview
2007 X-Yachts X-34 Shoal draft
Preview
2007 X-Yachts X-34 Shoal draft
Preview

Boat Overview

Specs

Main
NameValue
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX-34 Shoal draft
First built hull2007
VersionShoal draft
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialComposite_Material
General
NameValue
Top speed11.78 kmh
Length overall10.36 m
Length at waterline8.87 m
Beam overall3.41 m
Headroom1.86 m
Draft maximum1.58 m
Displacement5,299.77 kg
Ballast weight2,199.92 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area67.91 sq.m
Downwind sail area132.76 sq.m
Mainsail A434.00
Spinnaker A996.00
Engine
NameValue
Engine A
Power29 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement22.72
Downwind SA to Displacement44.42
Hull Displacement Speed 0.05
Displacement to Length (D/L) 7.23
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 1.98
