Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX-342 Fractional rigging
First built hull1988
VersionFractional rigging
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed11.14 kmh
Length overall10.4 m
Length at waterline8.14 m
Beam overall3.08 m
Beam hull1.86 m
Draft maximum1.86 m
Displacement4,200 kg
Ballast weight1,950 kg
Ballast typeCast iron / lead fin
Helm1 tiller (helm wheel in option)
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Number of spreaders1
Spreaders angle0 °
Upwind sail area68.19 sq.m
Downwind sail area109.44 sq.m
Engine
Engine B
Power18 HP
TypeInboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 26.63
Upwind SA to Displacement26.63
Downwind SA to Displacement42.75
Hull Displacement Speed 6.92
Displacement to Length (D/L) 217.16
Ballast to Displacement (B/D) 0.46
Capsize Screening Formula (CSF) 1.93
