Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.39 m
Specs
Main
| Name | Value |
|---|---|
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-35 |
| First built hull | 2005 |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Name | Value |
|---|---|
| Top speed | 11.8 kmh |
| Length overall | 10.39 m |
| Length at waterline | 8.87 m |
| Beam overall | 3.29 m |
| Draft maximum | 2.16 m |
| Displacement | 4,490.11 kg |
| Ballast weight | 1,700.06 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 74.04 sq.m |
| Downwind sail area | 132.11 sq.m |
| Mainsail A | 432.00 |
| Spinnaker A | 990.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 19 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 27.67 |
| Downwind SA to Displacement | 49.37 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.23 |
| Ballast to Displacement (B/D) | 0.38 |
| Capsize Screening Formula (CSF) | 2.01 |
