Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
11.34 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-37 Sport |
| First built hull | 2004 |
| Version | Sport |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 12.21 kmh |
| Mast height | 18.44 m |
| Length overall | 11.34 m |
| Length at waterline | 9.78 m |
| Beam overall | 3.51 m |
| Beam hull | 1.86 m |
| Draft maximum | 2.32 m |
| Displacement | 6,400.18 kg |
| Ballast weight | 2,715.2 kg |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Mast | 60.5 |
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 86.59 sq.m |
| Downwind sail area | 150.5 sq.m |
Engine
| Engine A | |
| Power | 29 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 25.55 |
| Downwind SA to Displacement | 44.41 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.59 |
| Ballast to Displacement (B/D) | 0.42 |
| Capsize Screening Formula (CSF) | 1.91 |
