Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.19 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | X-40 Shoal draft |
First built hull | 2004 |
Version | Shoal draft |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 12.78 kmh |
Length overall | 12.19 m |
Length at waterline | 10.7 m |
Beam overall | 3.84 m |
Headroom | 1.89 m |
Draft maximum | 1.56 m |
Displacement | 7,449.8 kg |
Ballast weight | 3,200.09 kg |
Ballast type | Cast iron fin with lead bulb |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Niels Jeppesen |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Number of spreaders | 3 |
Spreaders angle | Swept-back |
Upwind sail area | 99.22 sq.m |
Downwind sail area | 171.41 sq.m |
Mainsail A | 545.00 |
Spinnaker A | 1300.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 40 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 26.46 |
Downwind SA to Displacement | 45.7 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 7.94 |
Ballast to Displacement (B/D) | 0.43 |
Capsize Screening Formula (CSF) | 1.98 |
