Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.37 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-41 |
| First built hull | 2006 |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.78 kmh |
| Length overall | 12.37 m |
| Length at waterline | 10.7 m |
| Beam overall | 3.39 m |
| Draft maximum | 2.5 m |
| Displacement | 6,799.8 kg |
| Ballast weight | 2,730.17 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 98.29 sq.m |
| Downwind sail area | 202.06 sq.m |
Engine
| Engine A | |
| Power | 39 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 27.85 |
| Downwind SA to Displacement | 57.26 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.94 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 1.8 |
