Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX-41
First built hull2006
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed12.78 kmh
Length overall12.37 m
Length at waterline10.7 m
Beam overall3.39 m
Draft maximum2.5 m
Displacement6,800 kg
Ballast weight2,730 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Carbon fiber
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area98.29 sq.m
Downwind sail area202.06 sq.m
Engine
Engine A
Power39 HP
TypeInboard
Storage
Fuel tank A99.93 liter
Water tank A210.09 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 27.84
Upwind SA to Displacement27.84
Downwind SA to Displacement57.24
Hull Displacement Speed 7.94
Displacement to Length (D/L) 154.76
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 1.8
