Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.92 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-412 |
| First built hull | 1989 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 12.62 kmh |
| Length overall | 12.92 m |
| Length at waterline | 10.42 m |
| Beam overall | 3.69 m |
| Beam hull | 1.89 m |
| Draft maximum | 1.86 m |
| Displacement | 7,399.9 kg |
| Ballast weight | 3,499.92 kg |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 3 |
| Spreaders angle | 0 ° |
| Upwind sail area | 100.52 sq.m |
| Downwind sail area | 175.03 sq.m |
Engine
| Engine A | |
| Power | 41 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 26.92 |
| Downwind SA to Displacement | 46.88 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.84 |
| Ballast to Displacement (B/D) | 0.47 |
| Capsize Screening Formula (CSF) | 1.91 |
