Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.95 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | X-43 Sport |
First built hull | 2003 |
Version | Sport |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 13.21 kmh |
Length overall | 12.95 m |
Length at waterline | 11.49 m |
Beam overall | 3.96 m |
Draft maximum | 2.5 m |
Displacement | 8,600.1 kg |
Ballast weight | 3,699.95 kg |
Ballast type | Cast iron fin with lead bulb |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Niels Jeppesen |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum (carbon fiber as an option) |
Number of spreaders | 3 |
Spreaders angle | Swept-back |
Upwind sail area | 107.02 sq.m |
Downwind sail area | 185.43 sq.m |
Mainsail A | 575.00 |
Spinnaker A | 1421.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 40 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 25.93 |
Downwind SA to Displacement | 44.93 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 8.23 |
Ballast to Displacement (B/D) | 0.43 |
Capsize Screening Formula (CSF) | 1.95 |
