Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
12.95 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-43 Standard |
| First built hull | 2003 |
| Version | Standard |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 13.21 kmh |
| Length overall | 12.95 m |
| Length at waterline | 11.49 m |
| Beam overall | 3.96 m |
| Draft maximum | 2.19 m |
| Displacement | 8,600.1 kg |
| Ballast weight | 3,699.95 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 107.02 sq.m |
| Downwind sail area | 185.43 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 40 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 25.93 |
| Downwind SA to Displacement | 44.93 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 8.23 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 1.95 |
