Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
14.02 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-46 Shoal draft |
| First built hull | 2003 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 13.7 kmh |
| Length overall | 14.02 m |
| Length at waterline | 12.34 m |
| Beam overall | 4.18 m |
| Beam hull | 1.98 m |
| Draft maximum | 1.89 m |
| Displacement | 10,399.96 kg |
| Ballast weight | 4,500.09 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 126.72 sq.m |
| Downwind sail area | 219.16 sq.m |
Engine
| Engine A | |
| Power | 75 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 27.05 |
| Downwind SA to Displacement | 46.79 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 8.53 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 1.93 |
