2003 X-Yachts X-46 Standard

1558

Report error

2003 X-Yachts X-46 Standard

No gallery images

2003 X-Yachts X-46 Standard

Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX-46 Standard
First built hull2003
VersionStandard
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed13.7 kmh
Length overall14.02 m
Length at waterline12.34 m
Beam overall4.18 m
Beam hull1.98 m
Draft maximum1.86 m
Displacement10,400 kg
Ballast weight4,500 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area126.72 sq.m
Downwind sail area219.16 sq.m
Engine
Engine A
Power75 HP
TypeInboard
Storage
Fuel tank A199.87 liter
Water tank A380.06 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 27.04
Upwind SA to Displacement27.04
Downwind SA to Displacement46.77
Hull Displacement Speed 8.53
Displacement to Length (D/L) 154.08
Ballast to Displacement (B/D) 0.43
Capsize Screening Formula (CSF) 1.93
