Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX-482
First built hull1996
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed13.81 kmh
Length overall14.54 m
Length at waterline12.5 m
Beam overall4.3 m
Draft maximum2.5 m
Displacement12,000 kg
Ballast weight5,000 kg
Helm1 wheel
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioNiels Jeppesen
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area124.95 sq.m
Downwind sail area246.38 sq.m
Engine
Engine A
Power75 HP
TypeInboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 24.24
Upwind SA to Displacement24.24
Downwind SA to Displacement47.79
Hull Displacement Speed 8.58
Displacement to Length (D/L) 171.36
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 1.89
