Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
15.24 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-50 Shoal draft |
| First built hull | 2004 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 14.16 kmh |
| Length overall | 15.24 m |
| Length at waterline | 13.14 m |
| Beam overall | 4.27 m |
| Draft maximum | 2.17 m |
| Displacement | 12,399.84 kg |
| Ballast weight | 4,960.03 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 154.87 sq.m |
| Downwind sail area | 271.37 sq.m |
Engine
| Engine A | |
| Power | 75 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 29.4 |
| Downwind SA to Displacement | 51.52 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 8.8 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 1.86 |
