Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
16.76 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | X-55 Standard |
First built hull | 2005 |
Version | Standard |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 14.85 kmh |
Length overall | 16.76 m |
Length at waterline | 14.48 m |
Beam overall | 4.57 m |
Draft maximum | 3.23 m |
Displacement | 16,499.86 kg |
Ballast weight | 6,000.11 kg |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Niels Jeppesen |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum (carbon fiber as an option) |
Number of spreaders | 3 |
Spreaders angle | Swept-back |
Upwind sail area | 186.08 sq.m |
Downwind sail area | 324.7 sq.m |
Mainsail A | 1008.00 |
Spinnaker A | 2488.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 29.2 |
Downwind SA to Displacement | 50.96 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 9.24 |
Ballast to Displacement (B/D) | 0.36 |
Capsize Screening Formula (CSF) | 1.81 |
