Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
16.95 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-562 |
| First built hull | 1999 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 15.03 kmh |
| Length overall | 16.95 m |
| Length at waterline | 14.84 m |
| Beam overall | 4.61 m |
| Draft maximum | 2.9 m |
| Displacement | 18,500.2 kg |
| Ballast weight | 7,399.9 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 3 |
| Spreaders angle | 0 ° |
| Upwind sail area | 191.66 sq.m |
| Downwind sail area | 330.36 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 100 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 27.87 |
| Downwind SA to Displacement | 48.04 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 9.35 |
| Ballast to Displacement (B/D) | 0.4 |
| Capsize Screening Formula (CSF) | 1.76 |
