Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
18.29 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | X-612 Standard |
First built hull | 1995 |
Version | Standard |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 15.69 kmh |
Length overall | 18.29 m |
Length at waterline | 16.15 m |
Beam overall | 5.12 m |
Draft maximum | 2.93 m |
Displacement | 19,499.92 kg |
Ballast weight | 9,099.96 kg |
Ballast type | Cast iron fin with lead bulb |
Helm | 2 wheels |
Rudder | 1 semi-spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Niels Jeppesen |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | Single-strand (ROD) discontinuous |
Number of spreaders | 3 |
Spreaders angle | 0 ° |
Upwind sail area | 214.61 sq.m |
Downwind sail area | 364.37 sq.m |
Mainsail A | 935.00 |
Spinnaker A | 2987.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 30.13 |
Downwind SA to Displacement | 51.16 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 9.76 |
Ballast to Displacement (B/D) | 0.47 |
Capsize Screening Formula (CSF) | 1.92 |
