Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
18.29 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-612 Standard |
| First built hull | 1995 |
| Version | Standard |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 15.69 kmh |
| Length overall | 18.29 m |
| Length at waterline | 16.15 m |
| Beam overall | 5.12 m |
| Draft maximum | 2.93 m |
| Displacement | 19,499.92 kg |
| Ballast weight | 9,099.96 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 3 |
| Spreaders angle | 0 ° |
| Upwind sail area | 214.61 sq.m |
| Downwind sail area | 364.37 sq.m |
Engine
| Engine A | |
| Power | 110 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 30.13 |
| Downwind SA to Displacement | 51.16 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 9.76 |
| Ballast to Displacement (B/D) | 0.47 |
| Capsize Screening Formula (CSF) | 1.92 |
