Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
22.46 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-73 |
| First built hull | 2001 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 17.14 kmh |
| Length overall | 22.46 m |
| Length at waterline | 19.23 m |
| Beam overall | 6.04 m |
| Draft maximum | 3.23 m |
| Displacement | 39,899.77 kg |
| Ballast weight | 14,000.12 kg |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Carbon fiber |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 240.43 sq.m |
| Downwind sail area | 435.16 sq.m |
Engine
| Engine A | |
| Power | 100 HP |
| Type | inboard |
| Engine B | |
| Power | 125 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 20.95 |
| Downwind SA to Displacement | 37.91 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 10.64 |
| Ballast to Displacement (B/D) | 0.35 |
| Capsize Screening Formula (CSF) | 1.78 |
