Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
9.78 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X-99 |
| First built hull | 1985 |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 11.39 kmh |
| Length overall | 9.78 m |
| Length at waterline | 8.26 m |
| Beam overall | 2.77 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.77 m |
| Displacement | 2,980.1 kg |
| Ballast weight | 1,299.99 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | 5 ° |
| Upwind sail area | 62.25 sq.m |
| Downwind sail area | 110.18 sq.m |
Engine
| Engine A | |
| Power | 10 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 30.57 |
| Downwind SA to Displacement | 54.11 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 6.98 |
| Ballast to Displacement (B/D) | 0.44 |
| Capsize Screening Formula (CSF) | 1.95 |
