Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.13 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X4-0 Standard |
| First built hull | 2019 |
| Version | Standard |
| Price | 258,000 € |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.6 kmh |
| Length overall | 12.13 m |
| Length at waterline | 10.39 m |
| Beam overall | 3.84 m |
| Beam hull | 1.89 m |
| Draft maximum | 1.86 m |
| Displacement | 8,099.79 kg |
| Ballast weight | 3,049.95 kg |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | X-Yachts Design Group |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 78.04 sq.m |
| Downwind sail area | 176.98 sq.m |
Engine
| Engine A | |
| Power | 40 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 19.68 |
| Downwind SA to Displacement | 44.63 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.82 |
| Ballast to Displacement (B/D) | 0.38 |
| Capsize Screening Formula (CSF) | 1.93 |
