Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.5 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X4- 3 Shoal Draft |
| First built hull | 2016 |
| Version | Shoal draft |
| Price | 300,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 13.13 kmh |
| Length overall | 12.5 m |
| Length at waterline | 11.31 m |
| Beam overall | 3.96 m |
| Draft maximum | 1.86 m |
| Displacement | 8,850.03 kg |
| Ballast weight | 3,800.19 kg |
| Ballast type | Steel fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Niels Jeppesen |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 96.99 sq.m |
| Downwind sail area | 204.02 sq.m |
Engine
| Engine A | |
| Power | 45 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 23.06 |
| Downwind SA to Displacement | 48.5 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 8.16 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 1.93 |
