Boat Overview

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelX4-9 Deep draft
First built hull2018
VersionDeep draft
Price520,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed14.21 kmh
Length overall15.12 m
Length at waterline13.29 m
Beam overall4.51 m
Draft maximum2.47 m
Displacement12,900 kg
Ballast weight5,450 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioX-Yachts Design Group
Websitehttp://www.x-yachts.com/
Rig & Sails
Rotating spars
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingSingle-strand (ROD) discontinuous
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area129.32 sq.m
Downwind sail area302.21 sq.m
Engine
Engine B
Power57 HP
TypeInboard
Storage
Fuel tank A300.18 liter
Water tank A310.03 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 23.9
Upwind SA to Displacement23.9
Downwind SA to Displacement55.86
Hull Displacement Speed 8.85
Displacement to Length (D/L) 153.19
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 1.94
