Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
15.12 m
Specs
Main
| Name | Value |
|---|---|
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | X4-9 Standard |
| First built hull | 2018 |
| Version | Standard |
| Price | 520,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Top speed | 14.21 kmh |
| Length overall | 15.12 m |
| Length at waterline | 13.29 m |
| Beam overall | 4.51 m |
| Draft maximum | 2.17 m |
| Displacement | 12,900.16 kg |
| Ballast weight | 5,449.91 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | X-Yachts Design Group |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Rotating spars | |
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 129.32 sq.m |
| Downwind sail area | 302.21 sq.m |
| Mainsail A | 777.00 |
| Spinnaker A | 2476.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 57 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 23.91 |
| Downwind SA to Displacement | 55.88 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 8.85 |
| Ballast to Displacement (B/D) | 0.42 |
| Capsize Screening Formula (CSF) | 1.94 |
