Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.36 m
Specs
Main
| Maker | X-Yachts |
| Maker website | https://www.x-yachts.com |
| Model | Xc 35 Standard |
| First built hull | 2014 |
| Version | Standard |
| Price | 168,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 12.1 kmh |
| Length overall | 10.36 m |
| Length at waterline | 9.63 m |
| Beam overall | 3.54 m |
| Draft maximum | 1.89 m |
| Displacement | 6,450.08 kg |
| Ballast weight | 2,150.03 kg |
| Ballast type | Cast iron |
| Helm | 2 wheels |
| Rudder | 1 spade rudder |
| Cockpit | Closing aft cockpit with opening system |
Designer
| Naval architect | |
| Name/Studio | X-Yachts Design Group |
| Website | http://www.x-yachts.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Single-strand (ROD) |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 73.49 sq.m |
| Downwind sail area | 136.85 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 30 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 21.57 |
| Downwind SA to Displacement | 40.17 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.53 |
| Ballast to Displacement (B/D) | 0.33 |
| Capsize Screening Formula (CSF) | 1.92 |
