Name	Value
Maker	X-Yachts
Maker website	https://www.x-yachts.com
Model	Xc 38 Shoal draft
First built hull	2010
Version	Shoal draft
Price	299,000 €
Boat type	Sail
Category	Cruiser Boats
Hull type	Monohull
Hull material	Monohull

Name	Value
Top speed	12.59 kmh
Length overall	11.58 m
Length at waterline	10.39 m
Beam overall	3.84 m
Draft maximum	1.58 m
Displacement	8,699.89 kg
Ballast weight	3,774.79 kg
Ballast type	Cast iron fin with lead bulb
Helm	2 wheels
Rudder	1 spade rudder
Cockpit	Closing aft cockpit with opening system

Name	Value
Naval architect
Name/Studio	X-Yachts Design Group
Website	http://www.x-yachts.com/

Name	Value
Spars	Mast and boom in Aluminum
Number of spreaders	2
Spreaders angle	Swept-back
Upwind sail area	80.27 sq.m
Downwind sail area	175.12 sq.m
Mainsail A	475.00
Spinnaker A	1410.00

Name	Value
Engine A
Power	40 HP
Type	Inboard engine ; Diesel
Engine B

2010 X-Yachts Xc 38 Shoal draft

Boat Overview

Type

Maker

Hull type

Hull Material

Composite_Material

Category

Boat length (LOA)

11.58 m

See all details

Overview

Discover the Pro

Specs

Performance & Ratios

Name	Value
Sail Area to Displacement (SA/D)	10.61
Upwind SA to Displacement	19.3
Downwind SA to Displacement	42.11
Hull Displacement Speed	7.82
Displacement to Length (D/L)	215.94
Ballast to Displacement (B/D)	43.39
Capsize Screening Formula (CSF)	1.88
