Boat Overview

Specs

Main
NameValue
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelXc 45 Standard
First built hull2008
VersionStandard
Price467,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
NameValue
Top speed13.95 kmh
Length overall13.9 m
Length at waterline12.53 m
Beam overall4.33 m
Draft maximum2.19 m
Displacement13,219.94 kg
Ballast weight5,965.19 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
Designer
NameValue
Naval architect
Name/StudioX-Yachts Design Group
Websitehttp://www.x-yachts.com/
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD)
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area126.63 sq.m
Downwind sail area241.27 sq.m
Mainsail A660.00
Spinnaker A1938.00
Engine
NameValue
Engine A
Power80 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement23.04
Downwind SA to Displacement43.89
Hull Displacement Speed 0.05
Displacement to Length (D/L) 8.59
Ballast to Displacement (B/D) 0.45
Capsize Screening Formula (CSF) 1.85
