Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelXc 50 Standard
First built hull2010
VersionStandard
Price660,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed14.36 kmh
Length overall15 m
Length at waterline13.53 m
Beam overall4.6 m
Draft maximum2.38 m
Displacement16,085 kg
Ballast weight7,220 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
Designer
Naval architect
Name/StudioX-Yachts Design Group
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD)
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area133.22 sq.m
Downwind sail area253.07 sq.m
Engine
Engine A
Power100 HP
TypeInboard
Storage
Fuel tank A599.99 liter
Water tank A799.86 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 21.26
Upwind SA to Displacement21.26
Downwind SA to Displacement40.38
Hull Displacement Speed 8.93
Displacement to Length (D/L) 180.86
Ballast to Displacement (B/D) 0.45
Capsize Screening Formula (CSF) 1.84
